Function and performance

●The first adoption of the multi-color background lighting keyboard for lighting console, easy for virtually control

●Maximum up to 120 channels and 512 dimmers

●72 faders maximum up to 96 control faders or A/B cue

●3 pages of 24 sub-masters ,4 effect starters

●200 scenes control by automatic or manual

●9 effect with 120 steps per effect It can set up the operation direction and modify speed. Extended width LCD, keyboard type instruction.

●Wheel for figuration ,easy to operate ,it offers random access memory and IC card flash memory function

●Standard DMX-512 output

Technical Parameter:

        ●Working voltage: AC220V±10% 50HZ±2%

        ●Output signal:DMX-512(1990)

        ●Environmental temperature : -20℃～+45℃

        ●Relative hunidity:20%-90%

        ●Working environment: Ventilating well ,and where there is not a large amount of smoke and dust
